4WD Robotics Kit
Build and program your own robot car
$23.00Ships in 2–4 days
Bulkor type a quantity — hold Shift to step by 10
Quantity: 1- Form factor
- 4WD chassis, laser-cut MDF
- Controller
- Arduino UNO
- Built for
- Students & self-learners
Sensing
Detects obstacles and tracks lines with ultrasonic and IR sensors.
Hands-on learning
Learn motor control and Arduino programming, hands-on.
Programmable
Fully open to custom code.
Architecture & Performance
Technical Specifications
- Controller
- Arduino UNO
- Motor driver
- L298N dual H-bridge
- Motors
- 4x TT gear motors
- Wheels
- 4x 65mm rubber wheels
- Sensors
- HC-SR04 ultrasonic, 2x IR obstacle/line sensors
- Actuator
- 1x MG90S micro servo (sensor pan mount)
- Power
- 3S 18650 Li-ion battery holder (3 cells)
- Chassis
- 2-layer laser-cut MDF
- Indicators
- 3x LED (red, green, blue)
Frequently Asked Questions
Technical and operational inquiries regarding the 4WD Robotics Kit.
Complete Your Build
View All →
Talk to us about your needs
Our engineers can adapt this hardware to your requirements, or design something new around them.
